Projecta DC Charger
Intelli-Charge 9-32V 25A 5 Stage DC/Solar Lithium Dual Battery Charger
An advanced DC/solar battery charger engineered for todays sophisticated lithium iron phosphate batteries.
FEATURES
Lithium charging technology
Engineered for use with todays advanced lithium battery technology
Engine bay installation
Sealed to IP67, the IDC is dust, splash and shock proof and can safely operate in extreme temperatures up to 80°C
Dual charging modes
Engineered to work with both smart and conventional alternators
Dual input operation
Simultaneous dual battery charging from both solar and alternator inputs
Total safeguard protection
Over temperature, reverse connection, over/under and spark free protection
Comes with installation manual.
SPECIFICATIONS
PART NO - IDC25L
CHARGE TYPE - 5 Stage
ALTERNATOR INPUT VOLTAGE - 9-32Vdc
MAX SOLAR INPUT - 28Vdc, 360W
OUTPUT CURRENT
Input 9-11Vdc 20A,
Input 11-32Vdc 25A
BACK DRAIN ON AUX BATTERY - 9.5-10.5mA
CHARGING PROFILE
1st Soft Start: 1.25A
2nd Soft Start: 6.25A
Bulk Charge Current: 25A
Absorption Voltage: 14.5V
Float Voltage: 13.5V
BATTERY CAPACITY -50-250Ah
BATTERIES SUPPORTED - Lithium iron phosphate
SMART ALTERNATOR
| 12V: Turn On: 12.2-20V 24V: Turn On: 24.4-32V |
Turn Off: <11.9V Turn Off: <24V |
CONVENTIONAL ALTERNATOR
| 12V: Turn On: 13.4-20V 24V: Turn On: 26.8-32V |
Turn Off: <12.8V Turn Off: <25.6V |
OPERATING TEMPERATURE - minus 10°C to +80°C
Please contact our service department about a lithium battery system fitted to your vehicle utilising one of these chargers.
Projecta 25A 5 STAGE INTELLI-CHARGE 9-32V LITHIUM DUAL BATTERY CHARGER with Solar
Condition
New
Type
Normal
Description
Projecta DC 25A Lithium Charger W/Solar
